Description
This WSJB RC MK2 is an aluminium micro size jetboat hull kit.
This micro jetboat is a nice way to get you going in the jetboat world. Great for learning, prototyping, or testing before you start building your big boat. But above all, this is a super fun rc-project to build.
Its design is based on the WSJB 300 mini jetboat, which is an extremly stable hull. It will fit-up nicely with a TFL B54253 30mm jetpump (cut-out templates included), which gives it a juicy pace on the water. There is a pump frame available which is sold separatly, for easy mounting of the pump. The hull kit is made out of cnc laser cut, 2mm aluminium plates (AW 5754), which results in a perfect fit, easy TIG welding and an indestructible vessel.
Once finished it measures 68 x 31 x 24 cm and weighs appr 3kg.
Included in the kit:
– 1 Hull base
– 1 Transom
– 1 Transom mid
– 1 Transom cover
– 2 Chines
– 2 Sides (L+R)
– 2 Bow sides
– 1 Foredeck
– 1 Window front
– 2 Window sides (L+R)
– 1 Large engine bay cover
– 2 Swimdeck sides (L+R)
– Templates for TFL B54253 pump cut-outs
– Construction manual
The MK2 version has a re-designed engine bay compartment with new front deck, side panels and transom to support the bigger hatch. The bulhead is removed to create a much bigger opening into the engine bay, which can easily hold 2 batteries.
Order this MK2 DIY kit now to start your own custom build.
